CS-525

12寸号角专业音箱

12寸专业音箱
Mounted Drivers/单元 ..................woofer低音/12”Cone type
                               Tweeter/Horn type/号角高音
Frequency response/频率响应 ..........................55Hz-20kHz
Sound Pressure Level(SPL)/灵敏度.................97dB/1W/1m
Maximum(SPL)最大声压.....124dB/1m(Peak/峰值:128dB/1m)
Peak Input Power/最大输入功率...............................1200W
Music Input Power/音乐输入功率................................600W
Nominal Input Power(AES)/额定输入功率....................300W
Nominal Impedance/额定阻抗.........................................8Ω
Coverage Pattern(VxH)/覆盖角度............................100°x 70°
Dimensions(mm)/外形尺寸...............366(W)x596(H)x409(D)
Weight/净重...............................................21.15Kg/PCE/只
